ATEN CL3800NW DE Short Dual-Rail 18.5\" LCD console (USB HDMI DVI VGA) DE layout

The CL3800 USB HDMI DVI VGA LCD Console is a short depth dual rail LCD KVM console featuring an 18.5\" LED-backlit widescreen LCD monitor with an integrated keyboard and touchpad. The short-depth design fits all 19\" equipment cabinets, and is especially suitable for shallow racks. In addition to saving valuable space on the rack, the CL3800 also provides a space-saving solution for special environments, such as outside broadcast vans (OB vans) and compact control rooms. The CL3800 supports three types of video input – HDMI, DVI, and VGA – and provides the ultimate in installation flexibility by allowing users to connect the console and the computer via any of the three types of video source. The CL3800NW’s full HD widescreen LCD monitor ensures excellent video quality and provides ample viewing area. Furthermore, the dual rail design enables the LCD monitor, keyboard and touchpad to operate independently of each other. To maximize space utilization, the keyboard and touchpad modules can slide back to \"hideaway\" when not in use, while the thin profile LCD monitor rotates back, flush against the rack, to allow the convenient monitoring of computer activity. For added convenience, users can choose to manage the computer from an external console. The CL3800 features a port for an external USB mouse on the unit’s front panel, while ports for the second KVM console (USB keyboard/mouse and HDMI, DVI, or VGA monitor) are provided on the rear panel. The CL3800 also includes two mini stereo ports for connecting audio speakers. With a rich feature set, the CL3800 is designed to exceed the requirements for space utility optimization, superior video quality, adaptive deployment, and operational versatility, and is ideal for applications such as mobile live streaming in the broadcasting sector or control rooms with limited space in any industry. Models: CL3800NW: 18.5\" LCD screen with Full HD resolution of 1920 x 1080 CL3800NX: 18.5\" LCD screen with resolution of 1366 x 768 Space Utility Optimization Exclusive LED illumination light – designed by ATEN to illuminate the keyboard and touchpad to allow visibility in low-light conditions Integrated LCD KVM console with an 18.5\" LED-backlit widescreen LCD monitor in a dual rail housing with top and bottom clearance for smooth operation in a 1U high system rack Short-depth design allows you to work with your rack-mounting equipment in narrow spaces Dual rail design allows LCD monitor and keyboard/touchpad modules to operate independently Console lock – enables the console drawer to remain securely locked away in position when not in use Remarkable Audio/Video Experience: Support three types of video inputs – HDMI, DVI, and VGA 18.5\" LCD screen supports Full HD resolution of 1920 x 1080 @ 60Hz (CL3800NW) 18.5\" LCD screen supports resolution of 1366 x 768 @ 60Hz (CL3800NX) External console supports input video resolutions up to 1920 x 1200 @ 60Hz Audio support for connecting speakers Installation Flexibility: Standard rack mount kit included Optional Easy Installation Rack Mounting Kit available No software required Firmware upgradable Supports hot-plugging Reliability and Operational Versatility Supports an external console with USB / HDMI / DVI / VGA connectors (Only one video signal (HDMI, DVI-D, or VGA) can be displayed at time.) Additional hot-pluggable USB mouse port on front panel (also functions as a USB peripheral port) Console selection via hotkey Standard 105-key keyboard Keyboard Language support: English(US), English(UK), French, German, German(Swiss), Greek, Hungarian, Italian, Japanese, Korean, Russian, Spanish, Swedish , Traditional Chinese and Turkish The design complies to the UL 60950-1 and CAN/CSA standards Package Contents: 1x CL3800 LCD KVM Console with Standard Rack Mount Kit 1x USB HDMI KVM Cable (HDMI, USB, Audio 1.8 m/6 ft) 1x Firmware Upgrade Cable 1x Power Cord 1x User Instructions Device CL3800NW CL3800NX Computer Connections Direct 1 1 Console Selection Hotkey Hotkey Connectors External Console Ports 1 x HDMI Female 1 x DVI-D Female (White) 1 x HDB-15 Female (Blue) 2 x USB Type A Female 1 x 3.5mm Audio Jack Female (Green) 1 x HDMI Female 1 x DVI-D Female (White) 1 x HDB-15 Female (Blue) 2 x USB Type A Female 1 x 3.5mm Audio Jack Female (Green) KVM Ports 1 x HDMI Female 1 x DVI-D Female (White) 1 x HDB-15 Male (Blue) 1 x USB Type B Female 1 x 3.5mm Audio Jack Female (Green) 1 x HDMI Female 1 x DVI-D Female (White) 1 x HDB-15 Male (Blue) 1 x USB Type B Female 1 x 3.5mm Audio Jack Female (Green) USB Port 1 x USB Type A Female 1 x USB Type A Female Firmware Upgrade 1 x 3.5mm Audio Jack Female (Black) 1 x 3.5mm Audio Jack Female (Black) Power 1 x 3-prong AC Socket 1 x 3-prong AC Socket Switches Reset 1 x Semi-recessed Pushbutton 1 x Semi-recessed Pushbutton Firmware Upgrade 1 x Slide 1 x Slide Power 1 x Rocker 1 x Rocker LCD Power 1 x Pushbutton 1 x Pushbutton LCD Adjustment 4 x Pushbutton 4 x Pushbutton LEDs Power 1 x KVM Console (Dark Green) 1 x LCD (Orange) 1 x KVM Console (Dark Green) 1 x LCD (Orange) Lock 1 x Num Lock (Green) 1 x Caps Lock (Green) 1 x Scroll Lock (Green) 1 x Num Lock (Green) 1 x Caps Lock (Green) 1 x Scroll Lock (Green) Video Input Video Resolution 1920 x 1200 @ 60 Hz, DDC2B 1920 x 1200 @ 60 Hz, DDC2B Panel Spec LCD Module 18.5\" TFT-LCD 18.5\" TFT-LCD Resolution 1920 x 1080 @ 60 Hz 1366 x 768 @ 60 Hz Pixel Pitch 0.213 mm x 0.213 mm 0.3 mm x 0.3 mm Response time 20 ms 5 ms Viewing Angle 178° (H), 178° (V) 170° (H), 160° (V) Contrast Ratio 1000 : 1 1000 : 1 Support Color 16.77M colors 16.77M colors Luminance 350 cd/m² 250 cd/m² Emulation Keyboard / Mouse USB USB Maximum Input Power Rating 100–240V AC 50–60Hz 1A 100–240V AC 50–60Hz 1A Power Consumption AC110V:26.6W:140BTU AC220V:26.8W:141BTU AC110:18.3W:101BTU AC220:17.8W:98BTU Environmental Operating Temperature 0-40°C 0-40°C Storage Temperature -20-60°C -20-60°C Humidity 0 - 80% RH, Non-condensing 0 - 80% RH, Non-condensing Physical Properties Housing Metal Metal Weight 9.61 kg ( 21.17 lb ) 9.79 kg ( 21.56 lb ) Dimensions (L x W x H) 48.06 x 51.42 x 4.28 cm (18.92 x 20.24 x 1.69 in.) 48.06 x 51.42 x 4.28 cm (18.92 x 20.24 x 1.69 in.) Body Dimensions(L x W x H) 44.92 X 46.74 X 4.28 cm (17.69 x 18.40 x 1.69 in.) 44.92 X 46.74 X 4.28 cm (17.69 x 18.40 x 1.69 in.) Note Body Dimensions exclude I/O ports, handles, and mounting brackets. Body Dimensions exclude I/O ports, handles, and mounting brackets. Note For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
